ST511C除静电除尘离子棒

http://chinastatic.cn.ailbaba.com

ST 511C离子棒ST511C Induced Static Bar

ST511C离子棒,其直径100mm内可迅速清除物体表面表电,属工业类,。方型不锈钢棒体适用于各种机械设备内除静电装置，需配ST401A高压发生器使用。

ST511C Induced Static Bar, Its 100mm diameter table surface objects can be removed quickly -- are industrial categories. Square steel rods body applicable to the installation of mechanical equipment, except electrostatic, To be Configuration ST401A pressure generator.

 Specification(技术参数)

Operating voltege(工作电压)	5.6KV
Current consumption(消耗电流)	230uA/M
Operating Temperature(操作温度)	-10～50℃
Weight(重量)
HV Cable length(高压电缆长度)	2 Mertres
Max.Length(**大长度)	2 Mertres

Decay tdst Results (测试结果)

Testing Conditions(测试条件)
Test voltage(测试电压)：5KV-500V Operating Voltage(操作电压)：5.6KV Temperature(环境温度)：22℃
Distance(距离)		30mm	90mm	150mm
Decay time (中和时间)	Positive(正)	0.1s	0.2s	0.5s
	Negative(负)	0.2s	0.2s	0.7s
Offset voltage (残余电压)	Positive(正)	25V	24V	18V
	Negative(负)	-30V	-25V	-12V
