SHIMADZU齿轮泵SGP1A

发布时间 2019-09-17 16:47:54

产品描述

SHIMADZU齿轮泵SGP1A

型号︰	SGP1A
品牌︰	SHIMADZU
原产地︰	日本
单价︰	CNY ? 4500 / 件
**少订量︰	1 件

共有 38 相关信息

上一个

下一个

12345678910</ｓｅｌｅｃｔ> 秒

自动翻页︰ <ｓｅｌｅｃｔ name="autoSecond">

产品描述

SHIMADZU齿轮泵SGP1A
SHIMADZU GEAR PUMPS

SGP1,SGP2 series

SGP1 and SGP2 series high pressure gear pumps are an advanced version of conventional gear pumps using specialized cast iron body. They can withstand any adverse conditions of surge pressure, wide temperature and wide speed range with long life. Especially they maintains high performance during high temperature and low speed operation. Ceramic coating in SGP2 pump realizes invented step in sealing device for leakage loss

SGP1型系列齿轮泵是一种具有轴向间隙自动补偿和径向液压平衡的外啮合齿轮泵，采用了三开式结构，轴套内装有DU衬套，侧板为双金属材料；前盖、后盖为铝合金压铸件，中间体为铸铁件；从而有效地提高了齿轮泵的性能指标和可靠性。

型号	理论排量 mL/r	额定压力MPa	**高压力 MPa	**高转速 r/min	**低转速 r/min
SGP1-16	15.9	20.5	24.53	4000	400
SGP1-18	17.9
SGP1-20	20.0
SGP1-23	23.3
SGP1-25	24.5			3500
SGP1-27	27.3			3500
SGP1-28.2	28.2			3000
SGP1-30	29.2
SGP1-30.8	30.4
SGP1-31.9	31.5
SGP1-32	32.4
SGP1-34	33.2
SGP1-36	35.7

型号	**高压力	额定压力	排量	配管尺寸				容许转数rpm		重量（kg）
	（MPa）	（MPa）	m?/rev	入口		出口		容许转数rpm
				L型	F型	L型	F型	**低	**高
SGP1A16	24.5	20.6	16.2	?25	PT1"	?19	PT3/4"	500	4000	3.3
SGP1A18	24.5	20.6	18.3	?25	PT1"	?19	PT3/4"	500	4000	3.4
SGP1A20	24.5	20.6	20,4	?25	PT1"	?19	PT3/4"	500	4000	3.5
SGP1A23	24.5	20.6	23.7	?25	PT1"	?19	PT3/4"	400	4000	3.7
SGP1A25	24.5	20.6	24.9	?25	PT1"	?19	PT3/4"	400	3500	4
SGP1A27	24.5	20.6	27.8	?25	PT1"	?19	PT3/4"	400	3500	4
SGP1A30	24.5	20.6	29.9	?25	PT1"	?19	PT3/4"	400	3000	4.1
SGP1A32	24.5	20.6	33.2	?25	PT1"	?19	PT3/4"	400	3000	4.2
SGP1A34	20.6	18.6	34.1	?25	PT1"	?19	PT3/4"	400	3000	4.3
SGP1A36	20.6	17.2	36.6	?25	PT1"	?19	PT3/4"	400	3000	4.5
